Elite
ES-EL150
Hurricane Resistant
The ES-EL150 is a fixed window available in a variety of shapes, allowing a wide range of applications. This window is used to bring light to places with difficult accessibility.
Frame Color
System Description:
- Large missile impact rated
- Frame depth: 2 15/16″
- Designed for laminated and insulating glass
- Tested water infiltration: 12 psf
- Tested design load: +80/-80 psf
- Maximum size: 54″ width x 120″ height
- U-value: 0.51 – IGU (1/8″ SB70 + AS + 1/8″ Clear + 0.090 PVB + 1/4″ Clear) 1.01 – LG (3/16″ Clear + 0.090 PVB + 3/16″ Clear)
- Insulating laminated glass: 1/8″ + 5/16″ AS + 1/8″ + 0.090 Interlayer + 1/4″
5/32″ + 5/16″ AS + 5/32″ + 0.090 Interlayer + 5/32″ - Laminated glass: 1/8″ + 0.090 Interlayer + 1/4″
3/16″ + 0.090 Interlayer + 3/16″ - SHGC: 0.26 on clear insulating laminated SB 70
- Flange frame for masonry, fin frame for wood construction or flush frame for concrete openings
- Architectural shapes available
- Minimum radius: 14″
- Saflex PVB, Kuraray PVB, Vanceva Storm and SentryGlas Plus interlayer options
